Description
VHF/VHF, UHF/UHF Simultaneous Receive
The IC-2730E provides VHF/VHF, UHF/UHF simultaneous receive capability as well as VHF/UHF receive. Main dials, volume, squelch knobs and primal buttons are symmetrically laid out for each band.
Optional VS-3 Bluetooth® Headset
The optional VS-3 Bluetooth® headset can wirelessly control the IC-2730E with three programmable keys and a PTT button. It also provides VOX operation for hands-free communication.
*Eine optionale Bluetooth®-Einheit UT-133/A muss im IC-2730E installiert sein.
Easy-to-See Large White Backlit LCD
The display size of the IC-2730E is 1.5 times larger than its predecessor, the IC-2725E. Frequency display and channel names are larger, and the white backlit provides higher contrast.
Easy Controller Mounting with the Optional MBF-1
The combination of the optional MBF-1 suction cup mounting base and MBA-5 controller bracket provides easy tilt and swivel adjustments. The large suction cup can be mounted on flat surfaces and can be removed easily.
Fig. Shows the optional MBF-1. The optional bracket MBA-5 is located on the back.
50W of output on VHF and UHF
The IC-2730E employs a durable PA module and delivers 50 watts of high power operation on both VHF and UHF bands.
Built-in 50 CTCSS and 104 DTCS tones with Split Tone Function
The CTCSS and DTCS tones are built-in for quiet stand-by and repeater access. The split tone function allows you to set CTCSS/DTCS tones separately for repeater uplink and downlink on a per channel basis.
Controller Attachment to the Main Unit with Optional MBA-4
With the optional MBA-4 combination bracket, the controller can be attached to the main unit. The microphone jacks are mounted on both the controller and main unit.
Wideband Receiver
The IC-2730E covers 118–174 and 375–550MHz*. You will be able to listen to aviation, marine, weather channels and other utility communications.* Receiver range differs depending on version.
Optional Active Noise Canceling Microphone
The optional active noise canceling microphone HM-209 can automatically reduce noise in extremely noisy environments and assist in transmitting clear and accurate audio.
Other Features
- HM-207 remote control microphone
- CS-2730 Free download PC programming software
- Versatile scanning capability
- Squelch delay and squelch attenuator
- Sub band auto mute function
- Sub band busy beep function
- Auto power off
- Time-out-timer
- 16 DTMF auto dial memories
- CI-V remote control capability (through the OPC-478UC)
Supplied accessories
- Hand microphone, HM-207
- Controller cable
- Microphone hanger
- DC power cable
- Spare fuses
Further information can be found in the download area
